4-Core LC/APC Fiber Cable – High-Speed 5G/FTTH Solution
Premium Fiber Optic Patch Cable for Ultra-Fast Data Transmission
Designed for high-speed 5G networks, FTTH (Fiber-to-the-Home) deployments, and data center interconnects, this 4-core LC/APC fiber optic cable ensures low-loss, bend-insensitive, and ultra-reliable performance. With premium G.657.A1 fiber and armored options, it supports high-density cabling, low-latency data transfer, and waterproof outdoor installations. Whether for telecom operators, ISPs, or enterprise networks, this LC/APC patch cable delivers future-proof connectivity with superior signal integrity.
🔍 Technical Specifications
| Parameter | Specification |
|---|---|
| Fiber Type | G.657.A1 (Bend-Insensitive) |
| Core Count | 4-Core |
| Connector Type | LC/APC (Angled Physical Contact) |
| Wavelength | 1310nm / 1550nm |
| Attenuation | ≤0.36 dB/km @ 1310nm, ≤0.22 dB/km @ 1550nm |
| Insertion Loss | ≤0.3 dB |
| Return Loss | ≥60 dB |
| Operating Temp. | -40°C to +85°C |
| Jacket Material | LSZH (Low Smoke Zero Halogen) / Armored |
| Standards Compliance | ITU-T G.657.A1, IEC 60793-2-50 |
🚀 Key Applications
✔ 5G Network Deployment – Ideal for 5G fronthaul and midhaul due to low latency and high bandwidth.
✔ FTTH (Fiber-to-the-Home) – Perfect for last-mile connectivity with bend-resistant and waterproof variants.
✔ Data Center Interconnect (DCI) – Supports high-density MPO breakout solutions for cloud and hyperscale DCs.
✔ Enterprise & Industrial Networks – Armored and plenum-rated options for harsh environments and fire safety compliance.
🌍 International Standards Compliance
✅ ITU-T G.657.A1 (Bend-Insensitive Fiber Standard)
✅ IEC 60793-2-50 (Single-Mode Fiber Specifications)
✅ RoHS Certified (Environmentally Safe)
✅ OFNP/OFNR Rated (Plenum & Riser Compliance)
❓ Frequently Asked Questions (FAQ)
Q1: Why choose LC/APC over LC/UPC for 5G networks?
A: LC/APC connectors provide lower back reflection (≥60 dB), making them ideal for high-power and long-distance 5G transmissions.
Q2: Is this cable compatible with existing FTTH infrastructure?
A: Yes, our 4-core LC/APC cable is fully compatible with GPON, XGS-PON, and NG-PON2 systems.
Q3: What makes G.657.A1 fiber better for FTTH?
A: G.657.A1 offers superior bend resistance, reducing signal loss in tight-spaced installations.
Q4: Do you offer custom lengths and configurations?
A: Yes! We provide custom-cut lengths, MPO breakout options, and bulk orders for large-scale projects.
🔹 Why Choose Our 4-Core LC/APC Fiber Cable?
Ultra-Low Loss & High Reliability
Bend-Insensitive for Easy Installation
5G & FTTH Optimized
Armored & Waterproof Options Available
Compliant with Global Telecom Standards
📞 Contact us today for bulk orders & OEM solutions! 🚀
